50 2014-07-30 127139 13
By pressing the ARROW UP key focus will move from the
horizontal menu to the parameter field area.
The parameter field area focus is indicated by
The horizontal menu is now shaded
The parameter field area has a blue frame
The selected parameter field highlighted with a dark
blue color
Use the 4 ARROW keys to move between the parameter fields.
A parameter value is changed by:
Pressing or to open the field for editing.
A numeric field can be entered directly without opening
it first – simply enter the number.
When the parameter is entered press one of the keys:
This enters the value and leaves the cursor on the
parameter field.
This enters the value and moves the cursor to the next
parameter field.
°
C
