Note…
If the sensor under test is a thermocouple sensor and the
manual compensation mode is selected in work orders, a
cold junction temperature must be defined.
The parameters in the workorder can be edited.
Note…
Only numeric data can be entered.
The BACK key cancels a selection/edit or returning
to previous menu. The ESC key can be used throughout
the process.
Select “Next
1
“ to proceed with the operation.
A workorder Scenario is displayed, giving a graphical display
of the setup and sensor connections.
Start the calibration by selecting “Start Calibration
1
”.
