MX Series 16
Output Parameter
MX30
MX45
MX60
MX90
MX135
V Lo: 300 A
V Hi:
150 A
V Lo: 600 A
V Hi: 300 A
V Lo: 900 A
V Hi: 450 A
Frequency
Range:
Standard: 16 Hz - 819.0 Hz (for –HV option range, 45 Hz – 819.0 Hz)
-LF option:
16 Hz - 500.0 Hz
-HF opt
ion: 16 Hz – 905 Hz
Resolution:
0.01 Hz from 16.00 to 81.91 Hz
0.1 Hz
from 82.0 to 819.0 Hz
Accuracy:
± 0.01 %
±0.15 % for
–FC option
Phase (3 phase mode)
Range:
Phase B/C relative to phase A
0.0 to 360.0°
Resolution:
0.1°
Accuracy:
16 Hz - 100 Hz: < 1.5°
100 Hz
- 500 Hz: < 2°
> 500 Hz:
< 4°
±0.15 % for
–FC option
Ext. Sync Mode (not available with -FC option)
Input:
Isolated TTL input for external frequency control. Requires 5V at 5 mA for
logic hi
gh.
Accuracy:
Ext. Sync to phase A with fixed Ext. Sync Frequency input:
16 Hz
- 100 Hz: < 2°
100 Hz
- 500 Hz: < 3°
> 500 Hz:
< 4°
±0.15 % for –FC option
Programmable Output Impedance (available on MX30-3Pi and MX45-3Pi in three phase mode only)
Range:
R: 1 – 200 mOhm
L: 15
– 200 uH
N/A
N/A
N/A
Resolution:
R: 1 mOhm
L: 1 uH
N/A
N/A
N/A
Accuracy:
10 % FS
N/A
N/A
N/A
Note: Output specifications apply below the Current / Voltage rating lines shown in the V/I
rating chart below.

Ametek MX30-1 Specifications
