Ametek MX30-1 User Manual

User Manual – Rev AV AMETEK Programmable Power
MX Series 61
P8 / P9
Description
20
300 VRNG:
300 V AC Range Select
21
COM:
Common. Signal return.
22
/REM OFF:
Remote Off Control not
23
COM:
Common. Signal return
24
FLK/BYP:
Flicker / Bypass OMNI control
25
/OVL:
Overload not
26
CLA:
Current Limit A. Programmed current limit reference for phase A
27
CLC:
Current Limit C. Programmed current limit reference for phase C
28
CSB:
Current Sum Phase B.
29
N/C
30
FLT B:
Amplifier Fault Phase B
31
N/C
32
DC:
DC mode control
33
INP OFF:
Input power control
34
A ERR HI:
Error Signal Phase A, high
35
N/C
36
B ERR LO:
Error Signal Phase B, low
37
C ERR HI:
Error Signal Phase C, high
Table 3-4: System Interface Connectors
3.7.2 Analog Input Connector
Input screw-terminal strip. Functions are called out on rear panel decal. Table shows connections
from left to right when standing at the rear of the MX cabinet.
Pin
Description
1
RPV HI.
INPUT: Analog input for External Modulation
2
RPV Lo.
INPUT: return.
3
EXT SYNC HI
INPUT: Analog input for external sync mode.
4
EXT SYNC Lo
INPUT: return.
5
RI:
INPUT: Remote Inhibit. (See paragraph 3.12.)
6
RI:
INPUT: return.
Table 3-5: Analog Interface Connector
