User Manual – Rev AV AMETEK Programmable Power
MX Series 62
3.7.3 BNC Connectors
BNC connectors. Functions are called out on rear panel decal. Table shows connections from
left to right when standing at the rear of the MX cabinet.
Table 3-6: BNC Connectors
BNC
Description
1
Trigger Input (TTL input)
2
Trigger Output (TTL output) (Same signal connection as Function Strobe. Some units
may not have this output connected. If you don’t
get an output trigger on this BNC, use
the Function Strobe BNC instead.)
3
Function Strobe (TTL output) (Same signal connection as Trigger Output)
4
Clock (TTL output on Master / TTL input on Auxiliary)
5
Lock (TTL output on Master / TTL input on Auxil
iary)
6
Emergency Shut off inter connect. Installed only on
–MB systems with –ES Option.
Table 3-7: BNC Connectors
3.7.4 External Sense Connector
Pin
Description
1
Phase A sense
2
Phase B sense
3
Phase C sense
4
Neutral sense
Table 3-8: External Sense Connector
