Ametek MX30-1 User Manual

User Manual – Rev AV AMETEK Programmable Power
MX Series 23
2.1.7 Unit Protection
Input Over current:
In-line fast acting fuses. Check fuse rating in Service and Maintenance
section. Ratings will
depend on AC input configuration settings.
Circuit breaker for LV supply.
Input Over voltage:
Automatic shutdown.
Input Over voltage
Transients:
Surge protection to withstand EN50082-1 (IEC 801-4, 5) levels.
Output Over current:
Adjustable level constant current mode with programmable set point.
Output Short Circuit:
Peak and RMS current limit.
Over temperature:
Automatic shutdown.
2.2 Mechanical
Parameter
Specification
Dimensions:
(for each MX chassis)
Height: 50.0” 1270 mm
Width:
28.75” 731 mm
Depth:
34.5” 876 mm
Unit Weight:
(for each MX chassis)
Net: 1150 lbs / 522 Kg approximately
Shipping:
1231 lbs / 560 Kg approximately
Material:
Steel chassis with aluminum panels and covers.
Finish:
Light textured painted external surfaces.
Panels semi
-gloss polyurethane color no. 26440 (medium gray)
Cooling:
Fan cooled with air intake on the front and exhaust to the rear.
Fans:
6 x 225CFM.
Air displacement
22 Cu Ft/sec. Max.
Internal Construction:
Modular sub assemblies.
Rear Panel
Connections:
(See section 3 for description of connections)
x Cable entry and strain relieve for AC input wiring
x Cable entry and strain relieve for output wiring
x External sense terminal block (Remote voltage sense)
x System interface (2x)
x Clock and Lock BNC's (requires -LKM or -LKS options)
x RS232, USB, GPIB, LAN (option)
x Trigger In BNC
x Trigger Out BNC
x Function Strobe BNC
x Output Status
