User Manual – Rev AV AMETEK Programmable Power
MX Series 25
Displays:
LCD graphics display:
A large high contrast LCD display with backlight provides easy to read
guidance through all setup operations. An adjustable viewing angle
makes it easy to read from all practical locations.
Status indicators:
Large and bright status indicators inform the user of important power
source conditions. The Remote lamp informs the user that the unit is
under remote control. The Overload lamp indicates that excessive
current is being drawn at the output. The Over temperature lamp
illuminates when internal heat sink temperatures are too high. The Hi
Range indicator is lit any time the unit is switched to the high voltage
range. The Output On/Off indicator is on when the power source output
relays are closed.
2.6 Special Features and Options
Controller Features
Mode:
Switches between 1 and 3 phase outputs. This mode is available on
models MX30
-3Pi and MX45-3Pi only.
Parallel Operation:
Up to three units can be paralleled in a three-phase configuration (with
one master controller and one or two auxiliary units). (MX60, MX90 and
MX135). Only the master unit requires a controller in this setup. The
auxiliary units are controlled through the system interface.
Clock and Lock Mode:
(Option -LKM and -
LKS
required).
Three units (all with controllers) can be connected in a three-phase
configuration using CLOCK and LOCK connections. Each unit requires
its own controller in this configuration. One unit acts as the master and
provides the reference clock to the auxiliary units.
Note: This option cannot
be combined with –HF option.
Controller:
Programmable controller front panel assembly.
Output Relay:
Standard output relay feature to isolate power source from the load.
Output On/Off:
The output relay can be used to quickly disconnect the load. A green
status indicator displays the status of the output relay.
Firmware / Software Options
- 704
Mil Std 704D & E test firmware.
Mil Std 704A, B, C, & F test software (refer to Avionics Software Manual
P
/N 4994-971 for details).
Note: Requires use of MXGui Windows application software provided on
CD ROM CIC496.
- 160
RTCA/DO-160D test firmware
RTCA/DO
-
160E test software (refer to Avionics Software Manual P/N
4994
-971 for details)..
Note: Requires use of MXGui Windows application software provided on
CD ROM CIC496.
- 411
IEC 61000-4-11 test firmware (Pre-compliance)
- 413
IEC 61000-4-13 test firmware
-A350
Airbus A350 ABD0100.1.8.1 Test software (refer to Avionics Software
Manual P/N 4994
-971 for details)..
Note: Requires use of MXGui Windows application software provided on
CD ROM CIC496.
-ABD
Airbus A380 ABD0100.1.8 Test software (refer to Avionics Software
Manual P/N 4994-971 for details)..
