User Manual – Rev AV AMETEK Programmable Power
MX Series 26
Note: Requires use of MXGui Windows application software provided on
CD ROM CIC496.
Airbus AMD24C Test software (refer to Avionics Software Manual P/N
4994
-971 for details)..
Note: Requires use of MXGui Windows application software provided on
CD ROM CIC496.
Boeing 787 Test software (refer to Avionics Software Manual P/N 4994-
971 for details)..
Note: Requires use of MXGui Windows application software provided on
CD ROM CIC496.
Watt Hour Measurements (Accuracy and Resolution. See Sec. 2.6.3.)
Output Voltage Range Options
Adds 400 V AC only output range.
Adds customer specified AC only output range. Contact factory for
details.
Emergency Shut off switch. This option key lock push button is installed
on the front panel of the master MX if ordered with the MX system. When
pushed in, the main AC contactor is opened disconnecting the AC input
power to the MX input transformer. Note that the controller (and LCD
display) will still be powered up but no power is available to the
amplifiers and there will be no output power either. The controller runs
off the LV supply, which must be turned off with the front panel breaker.
After the ES has been pushed, the provided key will be required to
release it. Once the ES button has been re
leased, the MX must be
powered down using the front panel circuit breaker and turned back on
to start up again.
For multibox MX Systems (MX90 and up with more than one
controller and front panel controls, each of which having an ES
emergency switch, to connect a BNC cable between the cabinets for the
ES connection. For 3 or more cabinets with controller, this BNC can be
daisy chained using BNC T connectors.
Do not misplace the 2 keys provided, as no duplicates are
available from CI. If lost, the ES switch must be replaced. In that case,
contact AMETEK Programmable Power customer service.
(service@programmablepower.com
).
Increases maximum output frequency to 905 Hz.
Note: This option cannot be combined with
–LKM or -LKS option.
Adds Ethernet interface (RJ45 connector) for local area network
connection..
Limits maximum output frequency to 500 Hz.
Clock and Lock system, Master. (Not available with –HF option)
Clock and Lock system, Auxiliary. (Not available with –HF option)
Multi-box Option. Provides additional controllers in Auxiliary units of
multi
-
cabinet configurations (MX60, MX90, MX135) to allow individual
MX45 units to be used stand
-alone.
Current Sink Option. Allows application of regenerative loads that feed
energy (current, power) back into the MX output stage. The
energy fed
back is returned to the AC line (utility) feeding the MX.
This option will step the frequency ≠0.15% of program frequency
