Ametek MX30-1 User Manual

User Manual – Rev AV AMETEK Programmable Power
MX Series 27
External Accessories (External to MX chassis)
7003-416-1
Input / Output wiring junction box. Connects two to six three-phase MX45
cabinet outputs, neutral and ground to a common output terminal block
housed in a metal enclosure junction box. Can also be used to connect
multiple MX chassis to common AC input service. See section
3.13
for
details.
7003-424-1
Output noise filter, 3 phase + neutral. May be used to reduce output
noise of MX30 or MX45 when testing EUT’s for conducted emissions.
This is an external filter that attenuates the 250 KHz ripple frequency on
the MX output by > 20 dB. The filter is rated for 125A per phase and 800
Hz. Fo
r multi-box configurations, one filter is required per chassis.
Connects to MX30 or MX45 three
-phase output terminal only.
7003-426-1
Output fuse box. Provides added protection for MX system
configurations consisting of more than 2 MX cabinets. (MX135, MX180,
MX225 and MX270).
2.6.1 -HV Option Specifications
The -HV option provides an AC only output range of 0 to 400 Vac L-N. Specifications unique to the -
HV option are shown in the table below.
Output Parameter
MX30
MX45
MX60
MX90
MX135
Modes
Pi Controller
AC
Voltage:
Ranges (L-N):
0 -400 V
Resolution:
0.1 V
Accuracy:
± 0.25% of Full Scale / ± 1.0 Vac rms
Output Coupling
AC coupled
Power (total power for all phases, either range, at full scale voltage)
AC Mode
30 KVA
45 KVA
60 KVA
90 KVA
135 KVA
Current
Note: Current, maximum amps per phase available between 50 and 100 % of voltage range.
MX30-1
76.5 A
MX30
-
3, per
phase
25.5 A
MX45-1
112.5 A
MX45
-
3, per
phase
37.5 A
MX60
-
3, per
phase
50 A
MX90
-
3, per
phase
75 A
MX135
-
3,
per phase
112.5 A
Peak Current
AC Mode
MX30-1
337.5 A
MX30
-
3, per
phase
112.5 A
MX45-1
337.5 A
MX45
-
3, per
phase
112.5 A
MX60
-
3, per
phase
225 A
MX90
-
3, per
phase
225 A
MX135
-
3,
per phase
337.5 A
Frequency:
Range:
45 Hz – 819 Hz
with –LF option: 45 Hz – 500 Hz
