User Manual - Rev AV AMETEK Programmable Power
MX Series 192
8. Top Assembly Replaceable Parts
Note that different generation MX units may use different sub assemblies. Check the serial tag on the
back of the MX to determine the applicable top assembly number to determine the correct sub assembly
or part required. For amplifiers, refer to the amplifier serial tag for the relevant amplifier top assembly part
number.
Ref.
CI P/N
Description
Vendor
Qty
Location
Top Assembly 7003-427 / 7003-422
A2
7003-421-1
Front Panel Assy. Prog. Osc.
AMETEK PP
1
7003-718-2
CPU board assy. All 3 phase
MX.
AMETEK PP
1
7003-718-4
CPU board assy. MX30-1,
MX45-1 only.
AMETEK PP
1
7000-723-4
Keyboard/Display assy.
AMETEK PP
1
Top Assembly 7003-400
A2
7003-401-1
Front Panel Assy. Prog. Osc.
AMETEK PP
1
5100-707-2
CPU / Phase A board assy.
AMETEK PP
1
7000-722-2
Phase B/C board assy.
AMETEK PP
1
7000-723-1
Keyboard/Display assy.
AMETEK PP
1
Top Assembly 7003-427
A1
7003-721-1
PC Assy. RS232 / GPIB / USB
AMETEK PP
1
A1
7003-721-2
PC Assy. RS232 / GPIB / USB /
LAN
AMETEK PP
1
A6
7003-722-1
PC Assy., Low Volt PSU
AMETEK PP
1
7003-723-1
Ripple Filter
AMETEK PP
1
Top Assembly 7003-422 / 7003-400
A1
7003-703-1
PC Assy. RS232 / GPIB
AMETEK PP
1
A1
7003-703-2
PC Assy. RS232 / GPIB
AMETEK PP
1
A6
7003-702-1
PC Assy., Low Volt PSU
AMETEK PP
1
Top Assembly 7003-427 / 7003-422 / 7003-400
A2
7003-408-1
Front Panel Assy., Auxiliary
AMETEK PP
1
A3
7003-715-1
PC Assy., System Interface
AMETEK PP
1
A4
7003-701-1
PC Assy., V / I Sense
AMETEK PP
1
A14
7003-713-1
PC Assy., PWR Interconnect
AMETEK PP
1
A10
7003-714-1
PC Assy., EMI Filter
AMETEK PP
1
A7
7003-418-1
Amplifier Assy., 15kVA
AMETEK PP
1
A8
7003-418-1
Amplifier Assy., 15kVA
AMETEK PP
1
A9
7003-418-1
Amplifier Assy., 15kVA
AMETEK PP
1
B1
241186
Fan, 3", 24VDC
NMB Technology
3110KLO5WB50-P00
1
CB1
270224
Circuit Breaker, 2.5A, 300V
AIRPAX
IELH111-1-61-2-50-D-01-V
1
K1
245235
Relay, 3C, 30A, 24VDC
Deltrol Controls
21014 - 82
1
K8
245235
Relay, 3C, 30A, 24VDC
Deltrol Controls
21014 - 82
1
K2
245236
Relay, 3C, 90A, 24VDC
EE Controls
EECLS47.22NTW
1
K6
245236
Relay, 3C, 90A, 24VDC
EE Controls
EECLS47.22NTW
1
K7
245236
Relay, 3C, 90A, 24VDC
EE Controls
EECLS47.22NTW
1
K9
245236
Relay, 3C, 90A, 24VDC
EE Controls
EECLS47.22NTW
1
K3
245237
Relay, 3C, 100A, 24VDC
EE Controls
1
