User Manual - Rev AV
AMETEK Program
mable Power
MX Series
188
7.6 Fuses
FUSE #
FUNCTION
FUSE VA
LUE
CI #
F1, F2, F3
AC mains input, 208 - 240V.
200A
270246
F1, F2, F3
AC mains input, 400 - 480V
110A
270226
F1
Power Module P
FC Fuse
100A
270249
F1
–
F8
AMP Heat Sink Fuses
30A
270168
Table 7-2: MX Fuse Ratings
