User Manual - Rev AV
AMETEK Program
mable Power
MX Series
194
Seq #
CI P/N
Description
Vendor
Qty
A
ssy. Number and Location
Top Assembly
7003-
400-01
F1
270246
FUSE, 200A, 600V
Ferraz Shawmut A6T
200
Littlefuse JLLS 200
1
F2
270246
FUSE, 200A, 600V
Ferraz Shawmut A6T
200
Littlefuse JLLS 200
1
For 208V / 230V Input
F3
270246
FUSE, 200A, 600V
Ferraz Shawmut A6T
200
Littlefuse JLLS 200
1
F1
270226
FUSE, 110A, 600V
Ferraz Shawmut A6T
110
Littlefuse JLLS 110
1
F2
270226
FUSE, 110A, 600V
Ferraz Shawmut A6T
110
Littlefuse JLLS 110
1
For 400V / 480V Input
F3
270226
FUSE, 110A, 600V
Ferraz Shawmut A6T
110
Littlefuse JLLS 110
1
A
mp
lifier A
ssy. 15kVA
7003-
418-1 / 7003-425-1 / 7003-433-
2
F1
270249
FUSE, 100A, 500V
Ferraz Shawmut A50QS100-4
3
A7, A8, A9
F1-F8
270168
FUSE, 30A, 600V
Bussmann KTK-30
Littlefuse KLK-30
24
A7, A8, A9
7003-713-1
Low Voltage Power Supply 7003-722-1
F1
270192
FUSE, Poly switch
Raychem RUE250
1
A6
F2
270192
FUSE, Poly switch
Raychem RUE250
1
A6
F3
270189
FUSE, Poly switch
Raychem RXEF110
1
A6
Low Voltage Power Supply 7003-702-1
F1
270192
FUSE, Poly switch
Raychem RUE250
1
A6
F2
270192
FUSE, Poly switch
Raychem RUE250
1
A6
Fan Control 7003-708-1
F1
270183
FUSE, 3A, 250V
Bussmann PCC3
1
A7-A8
F1
270183
FUSE, 3A, 250V
Bussmann PCC3
1
A8-A8
F1
270183
FUSE, 3A, 250V
Bussmann PCC3
1
A9-A8
F2
270192
FUSE, Poly switch
Raychem RUE250
1
A7-A8
F2
270192
FUSE, Poly switch
Raychem RUE250
1
A8-A8
F2
270192
FUSE, Poly switch
Raychem RUE250
1
A9-A8
Table 8-2: Fuses
