User Manual – Rev AV AMETEK Programmable Power
MX Series 22
Parameter
Specification
when not uses as Trig Out. This function is mutually exclusive with the
Function Strobe output.
Function Strobe:
Active for any voltage or frequency program change. 400 Ps pulse for voltage
or frequency change. Isolated TTL output. This function is mutually exclusive
with th
e Trigger Output. Same output is used for Trigger Output if Trigger
Output is programmed as part of list system.
Output Status:
Monitors status of output relay. Isolated TTL output. High if output relay is
closed, low if output rela
y is open.
Non volatile memory
storage:
Series I: 8 complete instrument setups and transient lists, 32 events per list.
Series II:
16 complete instrument setups and transient lists, 100 events per
list.
Waveforms
Sine (Models with Standard controller)
Si
ne, square, clipped, user defined (Models with Pi controller)
Transients
Voltage: drop, step, sag, surge, sweep
Frequency: step, sag, surge, sweep
Voltage and Frequency: step, sweep
IEEE-488 Interface:
SH1, AH1, T6, L3, SR1, RL2, DC1, DT1
Syntax: IEEE 488.2 and SCPI
Response time is 10 ms (typical)
RS232C Interface:
Bi-directional serial interface
9 pin D
-shell connector
Handshake:
CTS, RTS
Data bits:
7, 8
Stop bits:
1,2
Baud rate:
9600 to 115,200 bps
Syntax: IEEE 488.2
and SCPI.
Note
: Disconnect any USB connection when using the RS232 interface.
USB Interface:
Standard USB 1.1 peripheral.
Data transfer rate: 460,800 bps
Syntax: IEEE 488.2 and SCPI.
Note:
Use of the USB port to control more than one power so
urce
from a single PC is not recommended, as communication may not be
reliable. Use GPIB interface for multiple power source control.
LAN Interface:
Option –LAN. When the LAN interface is installed, the RS232 interface is
disabled.
RJ45 Connec
tor, 10BaseT, 100BaseT or 1000BaseT,
Data transfer rate: 460,800 bps
Protocol: TCP/IP.
Syntax: IEEE 488.2 and SCP
Note
: Disconnect any USB connection when using the LAN interface.
Current Limit Modes:
Two selectable modes of operation:
1.
Constant current mode (voltage folds back with automatic recovery)
2.
Constant voltage mode with trip-off (Relays open).
