User Manual - Rev AV AMETEK Programmable Power
MX Series 173
6.4.5 Output Cal 400 V DC Range(Series I only)
400 VDC Range Volt Zero: Press the PROGRAM key. Press the PROGRAM key and
select the 400 VDC Range. Program 0.0 VDC. Go to the
OUTPUT CAL screen and adjust the VOLT ZERO for 0.0 ±
0.005 volts DC on the output. Save this value by pressing the
SET key.
400 VDC Range + Full-scale: [Applies to MX Series I only] Program + 320.0 volts. Once the
output settings are made, turn on the ALC mode and allow the
output on all phases to settle. Next, proceed to the output
calibration screen. Select the VOLT +FS parameter and enter
the set voltage in the full-scale calibration window followed by
the ENTER key. A value between 0.9 and 1.1 will appear in the
window. Save this value by pressing the SET key.
