User Manual – Rev AV AMETEK Programmable Power
MX Series 57
3.6.6 MX180, MX225, and MX270 Output Wiring Diagram
Figure 3-11 shows the required output connections for a MX180-3Pi through MX270-3Pi three phase output configuration (rear-view
perspective). For MX180, only 4 cabinets are used and for MX225 only 5 but otherwise the wiring diagrams are the same so only the
complete MX270-3Pi configuration is shown.
Always disconnect all input power from the MX180, MX225 or MX270 before removing the front panel cover that provides access to the
input and output terminal connections. Route the wires from the back of the MX45 chassis to the front in the provided cable guides.
For any of these system configurations, it is recommended to use the optional wiring junction box (P/N 7003-416-1). See section 3.13 for
details. All output wires must be of equal length so it is advisable to place the master unit at or near the physical center of the set of units.
To Next Page
