User Manual – Rev AV AMETEK Programmable Power
MX Series 88
The following top-level menu choices can be accessed from the MENU key:
Entry Description
MENU 1
PROGRAM The PROGRAM menu allows output parameters the be
changed.
MEASUREMENTS The MEASUREMENTS screens are not menus in that no user
entries are required.
TRANSIENTS The TRANSIENTS menu allows output transients to be
programmed.
WAVEFORMS The WAVEFORMS menu allows different waveforms to be
selected from the waveform library.
MORE The MORE selection causes the second part of the MENU
screen to be displayed. (MENU 2)
MENU 2
ADVANCED MEAS. The ADVANCED MEAS. screens are for display only. No user
entries are required.
APPLICATIONS The APPLICATIONS menu provides access to the optional
firmware application programs that may be installed in the MX
Series AC source.
SETUP REGISTERS The SETUP REGISTERS menu allows complete instrument
settings and transient list programs to be saved to nonvolatile
memory.
MORE The MORE selection causes the third part of the MENU screen
to be displayed. (MENU 3)
MENU 3
UTILITY The UTILITY menu provides access to less commonly used
setup screens such as those for the GPIB and RS232C (also
applies to USB and LAN) interface settings, initial startup
values, etc.
OUTPUT IMPEDANCE The OUTPUT IMPEDANCE menu provides control of the AC
source output impedance. (MX30-3Pi or MX45-3Pi model
only)
MEASUREMENT CAL The MEASUREMENT CAL menu allows for calibration of the
AC source measurement system.
OUTPUT CAL The OUTPUT CAL menu allows for calibration of the AC source
output.
Following the Menu overview pages is a detailed description of each menu and sub menu.
