170 ASC110 / ASC130 / ASC150
3.6. Individual Operations of Maintenance
2
3
2
Every 2000 Hours or Every 2 Years Every 2000 Hours or Every 2 Years
Exchanging the filter element of pressure filter
Exchange the filter element always in the following
occasions:
- when changing oil
- if the signal lamp of pressure filter (29) lights
up after the working temperature reached 50
through 60 °C (122 - 140 °F).
• Dismantle the filter container (2) using wrench 27.
• Take out the filter element (3).
• Carefully clean the filter container.
• Clean the contact surface of the filtration block from the
lower side.
• Check the condition of sealing rings and lubricate
them with clean oil.
• Insert a new element into the filter container - tighten
with torque of 40 + 10 Nm (30 + 7 lb ft).
! NOTE !
Use original filter elements according to spare
parts catalogue only.
Used filter elements are environmentally
dangerous waste - have them liquidated.
• Dismantle the filter container (2) /CE/.
