Transport gear selector (2)
When the gear selector is on, the transport gear is enga-
ged (”rabbit” signal lamp of the selector is on). The
machine can reach the maximum speed at reduced towing
power and reduced climbing capacity.
NOTE:
When the selector is off, the working gear mode is selec-
ted. The machine can reach the maximum towing power
and climbing capacity - see pre-selector (3).
! NOTE !
Selector (2) - transport gear - can be activated
when driving on finished surface.
It is possible to activate the selector while loaded.
Should towing power be insufficient, turn the
transport gear selector off.
Do not activate the selector while
working with the machine!
Do not turn the selector off at higher
speeds - this will cause rapid decele-
ration and impact in the hydraulic
system. Turn the selector off at low
speeds or when the machine is
stopped!
Working gear pre-selector (3)
Use the pre-selector to choose one of three working gears
in both directions obr. 20. Maximum speeds reached in
pre-selector ”1” to ”3” positions correspond to common
working speeds used for compacting and are factory-pre-
set. The machine can reach the maximum towing power
(climbing capacity) in position ”3”.
! NOTE !
Pre-selector (3) can only be operated if selector (2)
is off.
Use positions 1 and 2 of the pre-selector on even
surface only.
Use position 3 of the pre-selector when climbing.
Parking brake push-button (4)
Use the brake of the machine when the engine is running.
The brake pilot lamp is shining. Then the operator can
leave the seat.
NOTE:
In this case the seat switch is not activated.
Emergency brake push-button (5)
In case of failure when it is not possible to stop the machine
by moving the travel control (1), emergency brake control-
led by push-button (5) must be used. Activate the emer-
gency brake by pressing the button; the roller will brake,
engine will stop and the signal lamp (23) will light up. Turn
the button in the direction of the arrow to release the brake.
! NOTE !
If the emergency brake is pushed, it is not possible
to start the engine.
Vibration switch (6)
Press the switch to turn on vibration. Press it again to turn
vibration off.
! NOTE !
The signal lamp will indicate ”on” status.
Vibration can only be turned on if selector (2) is off.
