DISPLAY INPUT/OUTPUT STATUS
0:OUTPUTS 1:INPUTS
SELECT NO.
AC:2Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 36: The Display I/O Status display
DISPLAY OUTPUT STATUS
0:IN A PANEL 1:ON A LOOP
SELECT NO.
AC:2Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 37: The Display Output Status display
Once entered the LCD will then display a description of what that input or output does and its current
state.
Brigade: Displays the Brigade Board I/O Status
BRIGADE STATUS (NP: 1)
OUTPUT 1: (FIRE ) OFF /NORM
OUTPUT 2: (FAULT ) OFF /NORM
OUTPUT 3: (SOUNDER ) OFF /NORM
OUTPUT 4: (SOUNDER ) OFF /NORM
PRESS > FOR INPUTS/RELAYS/AUXS
AC:2Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 38: Display Brigade Status
Once entered, the LCD will then display the inputs, outputs, relays and auxiliary devices status.
Network: Displays Network Status.
Is pressed to gain access to NETWORK STATUS.
Note: This option is only available if the system configuration is networked.
DISPLAY NETWORK STATUS
NIC VERSION: 0.0.00.00
0:NETWORK POINTS
1:REMOTE SLAVE MODULES
SELECT NO.
AC:2Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 39: Display Network Status
