Page 38
Network Points:
DISPLAY NETWORK POINTS
0:STATUS 1:POWER SUPPLY 2:BRIGADE
SELECT NO.
AC:2Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 40: Display Network Points
Network Points Screens are
STATUS: Press, Select network point e.g. Loop Number
POWER SUPPLY: Press to display Charger Volts, Battery Detected and Mains OK
BRIGADE: Press to display Operational or Non-Operational
Remote Slave Modules:
Select from Network Status Remote Slave Modules, then Module number.
Apollo Loop 1
TYPE:APOLLO LOOP NO:1 VER: 6.1
NP:1 MOD:4 STAT:NORMAL
REMOTE MODULE STATUS
AC:2Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 41: Display Remote Module Status
Note: The SYSTEM, AVALUES and ADD-ONS will increment by 1 if the network is configured
/ SYSTEM: Is pressed to access SYSTEM STATUS
SYSTEM STATUS
ALARMS:000 PRE-ALARMS:000 DISABLES:000
DEVICE FAULTS:00 MOD FAULTS:00
LOOP FAULTS:00 EXTRA DEVICES:00
WALK TEST:00 WDOG:00
APP: V 1.0 EN54
CONFIG:
AC:2Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 42: Display System Status
/ AValues: Is pressed to access AVALUES.
Select Loop Number and device number to show AVALUES
Loop 1 sensor 1
L1 S1 Z2
STAT: NORMAL
AVALUE:25 MODE:0 I:000 O:000
0:PRINT ENTRY
AC:2Z ALM:0 PALM:0 FLT:0 DIS:0
Figure 43: Analogue Values
To Next Page
