Programming
107
NXD-700i & NXT-CA7 7” Modero Touch Panels
Panel Runtime Operations
Serial Commands are used in the AxcessX Terminal Emulator mode. These commands are case insensitive.
Button Query Commands (Cont.)
?TXT Get the current text information.
Syntax:
"'?TXT-<vt addr range>,<button states range>,<optional index>'"
Variable:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).
optional index = This is used if a string was too long to get back in one command.
The reply will start at this index.
custom event type 1001:
Flag - Zero
Value1 - Button state number
Value2 - Actual length of string
Value3 - Index
Text - Text from the button
Text length - Button text length
Example:
SEND COMMAND Panel,"'?TXT-529,1'"
Gets the button 'OFF state' text information.
The result sent to the Master would be:
ButtonGet Id = 529 Type = 1001
Flag = 0
VALUE1 = 1
VALUE2 = 14
VALUE3 = 1
TEXT = This is a test
TEXT LENGTH = 14
Panel Runtime Operation Commands
ABEEP Output a single beep even if beep is Off.
Syntax:
"'ABEEP'"
Example:
SEND COMMAND Panel,"'ABEEP'"
Outputs a beep of duration 1 beep even if beep is Off.
ADBEEP Output a double beep even if beep is Off.
Syntax:
"'ADBEEP'"
Example:
SEND COMMAND Panel,"'ADBEEP'"
Outputs a double beep even if beep is Off.
