Programming
98
NXD-700i & NXT-CA7 7” Modero Touch Panels
Text Effect Names
The following is a listing of text effects names. This list is associated with the ^TEF command on page 97.
"^" Button Commands (Cont.)
^UNI Set Unicode text. For the ^UNI command (%UN and ^BMF command), the Unicode text is
sent as ASCII-HEX nibbles.
Syntax:
"'^UNI-<vt addr range>,<button states range>,<unicode text>'"
Variable:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).
unicode text = Unicode HEX value.
Example:
SEND_COMMAND Panel,"'^UNI-500,1,0041'"
Sets the button’s unicode character to ’A’.
Note: To send the variable text ’A’ in unicode to all states of the variable text
button 1, (for which the character code is 0041 Hex), send the following command:
SEND_COMMAND TP,"'^UNI-1,0,0041'"
Note: Unicode is always represented in a HEX value. TPD4 generates (through the Text
Enter Box dialog) unicode HEX values. Refer to the TPDesign4 Instruction Manual for
more information.
Text Effects
• Glow -S • Soft Drop Shadow 1 • Medium Drop Shadow 1 • Hard Drop Shadow 1
• Glow -M • Soft Drop Shadow 2 • Medium Drop Shadow 2 • Hard Drop Shadow 2
• Glow -L • Soft Drop Shadow 3 • Medium Drop Shadow 3 • Hard Drop Shadow 3
• Glow -X • Soft Drop Shadow 4 • Medium Drop Shadow 4 • Hard Drop Shadow 4
• Outline -S • Soft Drop Shadow 5 • Medium Drop Shadow 5 • Hard Drop Shadow 5
• Outline -M • Soft Drop Shadow 6 • Medium Drop Shadow 6 • Hard Drop Shadow 6
• Outline -L • Soft Drop Shadow 7 • Medium Drop Shadow 7 • Hard Drop Shadow 7
• Outline -X • Soft Drop Shadow 8 • Medium Drop Shadow 8 • Hard Drop Shadow 8
• Soft Drop Shadow 1 with outline • Medium Drop Shadow 1 with outline
• Soft Drop Shadow 2 with outline • Medium Drop Shadow 2 with outline
• Soft Drop Shadow 3 with outline • Medium Drop Shadow 3 with outline
• Soft Drop Shadow 4 with outline • Medium Drop Shadow 4 with outline
• Soft Drop Shadow 5 with outline • Medium Drop Shadow 5 with outline
• Soft Drop Shadow 6 with outline • Medium Drop Shadow 6 with outline
• Soft Drop Shadow 7 with outline • Medium Drop Shadow 7 with outline
• Soft Drop Shadow 8 with outline • Medium Drop Shadow 8 with outline
