Programming
118
NXD-700i & NXT-CA7 7” Modero Touch Panels
Intercom Commands
The following is a list of Intercom Commands:
Intercom Commands
^MODEL? Sets model name.
If the panel supports intercom hardware it will respond with its model name as
shown in the response below.
Older hardware or newer hardware that has intercom support disabled with not
respond to this command.
Syntax:
SEND_COMMAND <DEV>,"'^MODEL?'"
Variables:
None.
Example:
SEND_COMMAND TP1,"'^MODEL?'"
Panel response string if intercom enabled:
^MODEL-MVP-8400i
^ICM Modifies an intercom call.
The microphone and/or speaker are activated based on the initial mode value of the
intercom start command and the audio data packet flow is started upon receipt of
this command by the panel.
Note: For backwards compatibility, both ^ICM-TALK and ^ICM-LISTEN are sup-
ported. However, the TALK and LISTEN subcommands are ignored.
Syntax:
SEND_COMMAND <DEV>,"`^ICM-TALK`"
Variables:
None.
Example:
SEND_COMMAND TP1,"`^ICM-TALK`"
^ICS- Intercom start.
Starts a call to the specified IP address and ports, where initial mode is either 1 (talk)
or 0 (listen) or 2 (both). If no mode is specified 0 (listen) is assumed.
Note: No data packets will actually flow until the intercom modify command is sent to
the panel.
Syntax:
SEND_COMMAND <DEV>,"'^ICS-<IP>,<TX UDP port>,<RX UDP
port>,<initial mode>'"
Variables:
IP = IP Address of panel to connect with on an Intercom call.
TX UDP port = UDP port to transmit to.
RX UDP port = UDP port to receive from.
initial mode = 0 (listen) or 1 (talk) or 2 (hands free). 0 is the default.
Examples:
Example of setting up a hands free unicast call between two panels:
SEND_COMMAND TP1, "^ICS-192.168.0.3,9000,9002,2"
SEND_COMMAND TP2, "^ICS-192.168.0.4,9002,9000,2"
Example of setting up a multicast call where the first panel is paging two other pan-
els:
SEND_COMMAND TP1, "^ICS-239.252.1.1,9002,9000,1"
SEND_COMMAND TP2, "^ICS-239.252.1.1,9002,9000,0"
SEND_COMMAND TP3, "^ICS-239.252.1.1,9002,9000,0"
Example of setting up a baby monitor call where the first panel is listening to the
microphone audio coming from the second panel:
SEND_COMMAND TP1, "^ICS-192.168.0.3,9000,9002,0"
SEND_COMMAND TP2, "^ICS-192.168.0.4,9002,9000,1"
