Photo 3.7.3

5. The rest of the black plastic guides will have the screws in between them. See photo 3.7.4

Photo 3.7.4

6. When you reach yellow and the first white you will see the ink slot board attached to it. Remove all cables

connected to it and gently push up on the board. The board is only attached to 4 small tabs located on the

black plastic guides. See photo 3.7.5

Anajet mPower i-Series ServiceManual
