Analog Devices ADAV4601 User Manual

ADAV4601 System Design Document Confidential Information
Rev.1 August 2009 Analog Devices Page 103
C115 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C116 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C117 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C118 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C125 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C126 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C128 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C131 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C132 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C135 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C137 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C139 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C142 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C143 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C144 0.1u CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C130 1000pF CAP CERAMIC 1000PF 50V NP0 0603 Digikey PCC2151CT-ND
C133 1000pF CAP CERAMIC 1000PF 50V NP0 0603 Digikey PCC2151CT-ND
C28 0.1uF CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
J3 DIN41612 PCB CONNECTOR 96-PIN MALE FEC 1097922
J2 SOCKET, PCB DC POWER 2.1MM FEC 224-959 (PK10)
U2 IC, SM TRANSMITTER DIGITAL AUDIO FEC 1023448
U19 IC, SM RECEIVER DIGITAL AUDIO FEC 1023452
U26 USB Microcontroller Digikey 428-1680-ND
D12 DIODE, 1A 400V; 1N4004 FEC 9565027
J6 HEADER, 2 ROW VERT 20WAY FEC 9733744
J17 HEADER, 1 ROW 2WAY & JUMPER SOCKET FEC 1022247 & 150411
LK1 HEADER, 1 ROW 2WAY & JUMPER SOCKET FEC 1022247 & 150411
LK8 HEADER, 1 ROW 2WAY & JUMPER SOCKET FEC 1022247 & 150411
LK14 HEADER, 1 ROW 2WAY & JUMPER SOCKET FEC 1022247 & 150411
LK11 HEADER, 1 ROW 3WAY FEC 1022248 & 150-411
D3 LED, SMD PLCC-2 YELLOW FEC 1058412
D13 LED, SMD, GREEN FEC 1318243
U1 IC, SM NC7S TINY LOGIC FEC 1014136
U9 IC, SM NC7S TINY LOGIC FEC 1014136
U4 Buffer/Line Driver FEC 1013811
U5 Buffer/Line Driver FEC 1013811
U6 Buffer/Line Driver FEC 1013811
J7 SOCKETS, 4X PHONO, PCB FEC 1280670
J8 SOCKETS, 4X PHONO, PCB FEC 1280670
J13 SOCKETS, 4X PHONO, PCB FEC 1280670
J20 SOCKETS, 4X PHONO, PCB FEC 1280670
R108 0R RESISTOR, 0603 0R0 FEC 9331662
R143 0R RESISTOR, 0603 0R0 FEC 9331662
R196 100k SMD Resistor (0.063W) FEC 9330402
R26 10k RESISTOR, 0603 10K FEC 9330399
R111 10k RESISTOR, 0603 10K FEC 9330399
R1 10k RESISTOR, 0603 10K FEC 9330399
R96 10k RESISTOR, 0603 10K FEC 9330399
R27 1k RESISTOR, 0603 1K FEC 9330380
