ADAV4601 System Design Document Confidential Information
Rev.1 August 2009 Analog Devices Page 96
Bit No. Bit Name Description Default
Bit[12] Reserved Always write a 1 if writing to this register 1
Bits[11:7] Reserved Always write as 0 if writing to this register. 00000
Bits[6:4] Reserved Always write a 1 if writing to this register. 111
Bits[3:0] Reserved Always write as 0 if writing to this register. 0000
Address 0x0080 Reserved (Default: 0x00FE)
Address 0x0081 Reserved (Default: 0x8202)
Address 0x0085 Reserved (Default: 0x00FE)
Address 0x0086 Reserved (Default: 0x8202)
Address 0x008A SRC Configuration 3 Register (Default: 0x0032)
Table 51.
Bit No. Bit Name Description Default
Bits[15:7] Reserved Always write as 0 if writing to this register. 000000000
Bit[6] SRC2 Channel C enable Used to enable Channel C of SRC2. 0
0b = disabled
1b = enabled
Bits[5:4] SRC2 Channel C Input Select Used to select the serial data input for SRC2 Channel C. 11
00b =SDIN0
01b = SDIN1
10b = SDIN2
11b = SDIN3
Bit[3] Reserved Always write as 0 if writing to this register. 0
Bit[2] SRC2C Channel B enable Used to enable Channel B of SRC2. 0
0b = disabled
1b = enabled
Bits[1:0] SRC2C Channel B input select Used to select the serial data input for SRC2 Channel B. 10
00b =SDIN0
01b = SDIN1
10b = SDIN2
11b = SDIN3
Address 0x008C DAC Standby Register (Default: 0x0000)
Table 52.
Bit No. Bit Name Description Default
Bits[15:5] Reserved Always write as 0 if writing to this register. 0000000000
Bit[4] HP1 Standby Set to 0 after reset, which means the HP amplifier is in normal
mode but is still powered down.
0
0b = Amplifer in normal mode
