USER MANUAL
Menu Bar: File Menu
This menu is related to the project and files management.
Figure 41: File Menu
New Project
Creates a new project set of files. By default, projects are blank. The next step will be importing a SigmaStudio set of
files. A workspace where the project folder will be created and a project name will be requested.
Figure 42: New project
Open Project
Loads a previous project from disk. Application Layer GUI project files have the .grp extension.
Figure 43: Load project
Save All
Saves current project to disk (auto-save mode by default).
Quit
Exits from the application.
1) Browse to a
workspace directory
2) Select current
folder as workspace
Select .grp file and
click OK
