Address 0x008F Reserved (Default: 0x000A)
Address 0x0200 EEPROM Self Boot Control Register (Default: 0x0000)
Table 54.
Bit No. Bit Name Description Default
Bits[15] Self boot enable It initiates a self boot from the external EEPROM. 0
0b = normal operation
1b = initiates self boot
Bits[14:6] Reserved Always write as 0 if writing to this register. 000000000
Bit[5] Safe load target/slew
RAM
Initiates a safe load to target/slew RAM. Cleared when safe load
completed.
0
0b = finished
1b = safe load request
Bit[4] Safe load parameter
RAM
Initiates a safe load to parameter RAM. Cleared when safe load
completed.
0
0b = finished
1b = safe load request
Bits[3:0] Reserved Always write as 0 if writing to this register. 0000
Address 0x0316 EEPROM Device Address Register (Default: 0x0050)
Table 55.
Bit No. Bit Name Description Default
Bits[15:7] Reserved Always write as 0 if writing to this
register.
000000000
Bits [6:0] EEPROM device address 0x50 = sets external EEPROM address 1010000
Address 0x0317 EEPROM Data Address Register (Default: 0x0000)
Table 56.
Bit No. Bit Name Description Default
Bits[15:0] EEPROM start address 0x0000 = default address 0000000000000000
