ADAV4601 System Design Document Confidential Information
Rev.1 August 2009 Analog Devices Page 63
Filter Type Selection
Irrespective of the filter control chosen (gain or frequency), the filter type has to be configured. This will basically
dictate the filter shape and the Q-type that will define the behaviour of the filter response. To do so, select the
values from the drop menu:
Figure 63:
Multiplexers Wizard
This wizard allows control over a mux. The Application Layer GUI supports the muxes in SigmaStudio under the TV
Algorithms library.
Figure 64: Muxes wizard
Delay Wizard
Figure 65: Delay wizard
The delay wizard creates a single or multiple delay block control.
1) Select the number
of inputs
2) Select the inputs
names
3) Leave the default
