APPENDIX C – ADAV4601 BILL OF MATERIALS
The table below is the bill of materials for the ADAV4601 evaluation board. The minimum BOM required can be
found by just using the parts highlighted in green. These correspond to the components shown in Figure 76: Typical
Application Diagram.
Table 57. ADAV4601 Bill of Materials
Part Value Description ADI/Farnell/Digikey Order Codes
U16 IC, SM EEPROM SERIAL 64K FEC 9758070
U15 IC, SM EEPROM SERIAL 512K FEC 9758038
J12 T header (3-pin SIP header&1SIP header) FEC150411
U12 IC, SM LOGIC OCTAL BUFFER/DRIVER FEC 1236353
U8 ADAV4601 ADAV4601BSTZ
U17 ADG736 ADG736BRMZ
U18 Microprocessor Supervisory Circuit ADM809SARTZ
U14 IC SUPVSR W/RESET 2.63V SOT143-4 ADM811-3RARTZ
U35 IC REG LDO 1A PREC 1.8V SOT-223 ADP3338AKCZ-1.8
U27 IC REG LDO 1A PREC 3.3V SOT-223 ADP3338AKCZ-3.3
U28 IC REG LDO 1A PREC 3.3V SOT-223 ADP3338AKCZ-3.3
L18 0 Ohm FERRITE BEAD, 0805 600Z FEC 9331662
L1 600Z FERRITE BEAD, 0805 600Z FEC 1193423
L2 600Z FERRITE BEAD, 0805 600Z FEC 1193423
L8 600Z FERRITE BEAD, 0805 600Z FEC 1193423
L10 600Z FERRITE BEAD, 0805 600Z FEC 1193423
L14 600Z FERRITE BEAD, 0805 600Z FEC 1193423
L17 600Z FERRITE BEAD, 0805 600Z FEC 1193423
L23 600Z FERRITE BEAD, 0805 600Z FEC 1193423
C37 0.1uF SMD Capacitor FEC 3019482
C53 0.1uF SMD Capacitor FEC 3019482
C75 0.1uF SMD Capacitor FEC 3019482
C154 0.1uF SMD Capacitor FEC 3019482
C156 0.1uF SMD Capacitor FEC 3019482
C158 0.1uF SMD Capacitor FEC 3019482
C91 0.1uF SMD Capacitor FEC 3019482
C92 0.1uF SMD Capacitor FEC 3019482
C96 0.1uF SMD Capacitor FEC 3019482
C98 0.1uF SMD Capacitor FEC 3019482
C43 0.1uF CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C2 0.1uF CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C3 0.1uF SMD Capacitor FEC 3019482
C4 0.1uF SMD Capacitor FEC 3019482
C5 0.1uF SMD Capacitor FEC 3019482
C6 0.1uF SMD Capacitor FEC 3019482
C11 0.1uF SMD Capacitor FEC 3019482
C26 0.1uF CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C31 0.1uF CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C32 0.1uF CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C35 0.1uF CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C40 0.1uF CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
