Analog Devices ADAV4601 User Manual

ADAV4601 System Design Document Confidential Information
Rev.1 August 2009 Analog Devices Page 102
C39 0.1uF SMD Capacitor FEC 3019482
C60 0.1uF CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C180 0.1uF CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C181 0.1uF CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C188 0.1uF CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C191 0.1uF CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C200 0.1uF CAPACITOR, 0603 100NF 50V; Y5V FEC 431989
C23 0.1uF SMD Capacitor FEC 3019482
C25 0.1uF SMD Capacitor FEC 3019482
C33 100nF CAPACITOR, 0805 100NF 50V FEC 3019949
C8 10nF CAP CER 10000PF 50V 5% COG 0805 Digikey 490-1642-1-ND
C20 10nF CAP CER 10000PF 50V 5% COG 0805 Digikey 490-1642-1-ND
C24 10nF CAP CER 10000PF 50V 5% COG 0805 Digikey 490-1642-1-ND
C29 10nF CAP CER 10000PF 50V 5% COG 0805 Digikey 490-1642-1-ND
C41 10nF CAP CER 10000PF 50V 5% COG 0805 Digikey 490-1642-1-ND
C42 10nF CAP CER 10000PF 50V 5% COG 0805 Digikey 490-1642-1-ND
C34 12pF CAPACITOR, 0603 12PF 50V FEC 721979
C36 12pF CAPACITOR, 0603 12PF 50V FEC 721979
C162 18pF CAPACITOR, 0603 18PF 50V; NPO FEC 721992
C175 18pF CAPACITOR, 0603 18PF 50V; NPO FEC 721992
C97 2.2uF SMD Capacitor FEC 9402101
C99 2.2uF SMD Capacitor FEC 9402101
C1 10nF CAPACITOR, 0603 10NF 25V FEC 3019561
C7 10nF CAPACITOR, 0603 10NF 25V FEC 3019561
C15 1nF CAPACITOR, 0603 1NF NPO 50V FEC 317202
C9 22nF CAPACITOR, 0603 22NF 50V FEC 3019755
C82 100uF CAPACITOR, CASE C 100UF 6.3V FEC 9188800
C90 100uF CAPACITOR, CASE C 100UF 6.3V FEC 9188800
C93 100uF CAPACITOR, CASE E 100UF 16V FEC 9694404
C16 10uF CAPACITOR, CASE B 10UF 16V FEC 9753893
C38 10uF CAPACITOR, CASE C 10UF 35V FEC 9694471
C54 10uF CAPACITOR, CASE C 10UF 35V FEC 9694471
C59 10uF CAPACITOR, CASE C 10UF 35V FEC 9694471
C114 10uF CAPACITOR, CASE C 10UF 35V FEC 9694471
C127 10uF CAPACITOR, CASE C 10UF 35V FEC 9694471
C129 10uF CAPACITOR, CASE C 10UF 35V FEC 9694471
C134 10uF CAPACITOR, CASE C 10UF 35V FEC 9694471
C146 10uF CAPACITOR, CASE C 10UF 35V FEC 9694471
C76 10uF CAPACITOR, CASE B 10UF 16V FEC 9696792
C77 10uF CAPACITOR, CASE B 10UF 16V FEC 9696792
C78 10uF CAPACITOR, CASE B 10UF 16V FEC 9696792
C79 10uF CAPACITOR, CASE B 10UF 16V FEC 9696792
C84 10uF CAPACITOR, CASE B 10UF 16V FEC 9696792
C85 10uF CAPACITOR, CASE B 10UF 16V FEC 9696792
C183 220uF CAPACITOR, CASE E 220UF 6.3V FEC 9694340
C186 220uF CAPACITOR, CASE E 220UF 6.3V FEC 9694340
C205 220uF CAPACITOR, CASE E 220UF 6.3V FEC 9694340
C145 47uF CAPACITOR, CASE C 47UF 6.3V FEC 9694323
C147 47uF CAPACITOR, CASE C 47UF 6.3V FEC 9694323
