AND AD-4401A - 13. Option-01 BCD Output; 13.1. Pin Assignment

AD-4401A
Page 44
13. Option-01 BCD Output
13.1. Pin Assignment
Connector for the Option-01 BCD output
Connector: OTAX N361J040AU (A&D Part No.: 1JI361J040-AG)
Connector cover: OTAX N360C040B (A&D Part No.: 1JI360C040-B)
Pin No.
Description
Description
Pin No.
A1
1
2
B1
A2
4
8
B2
A3
10
20
B3
A4
40
80
B4
A5
100
200
B5
A6
400
800
B6
A7
1000
2000
B7
A8
4000
8000
B8
A9
10000
20000
B9
A10
40000
80000
B10
A11
100000
200000
B11
A12
400000
800000
B12
A13 OFF: Overload
ON: Positive
OFF: Negative
B13
A14 ON: Stable
ON: Net value
OFF: Gross or Tare value
B14
A15
Decimal point position
A15=ON, B15=ON, A16=ON, B16=ON: None
A15=OFF, B15=ON, A16=ON, B16=ON: 0.0
A15=ON, B15=OFF, A16=ON, B16=ON: 0.00
A15=ON, B15=ON, A16=OFF, B16=ON: 0.000
A15=ON, B15=ON, A16=ON, B16=OFF: 0.0000
B15
A16 B16
A17
Unit
A17=OFF, B17=OFF: None or kg
A17=ON, B17=ON: g
A17=OFF, B17=ON: t
A17=ON B17=OFF: lb (For USA only)
B17
A18
Strobe output
Hold input
B18
A19
Common
Common
B19
A20
Frame ground
Frame ground
B20
When the weight value is overloaded and the data output logic (bCdF-03) is set to negative logic (default), all
of the output data is turned ON.
A1
B1
A20
B20
