AND AD-4401A - Calibration Functions

AD-4401A
Page 83
21.3. Calibration Functions
CALF Modbus Item Setting Value Default
User
setting
01
400101
400102
Unit
0: None
1: g
2: kg
3: t
4: lb (For USA only)
2
(4)
02
400103
400104
Decimal point position
0: 0 (No decimal point)
1: 0.0
2: 0.00
3: 0.000
4: 0.0000
0
03
400105
400106
Minimum division 1, 2, 5, 10, 20, 50 d 1
04
400107
400108
Maximum capacity 0 to 999999 20000
05
400109
400110
Zero setting range 0 to 100% 2
06
400111
400112
Zero tracking time
0.0: Not used
0.1 to 5.0 s
0.0
07
400113
400114
Zero tracking width
0: Not used
1: 0.5 d
2: 1.0 d
3: 1.5 d
4: 2.0 d
5: 2.5 d
6: 3.0 d
7:3.5 d
8:4.0 d
9:4.5 d
0
08
400115
400116
Stability detection time
0.0: Not used
0.1 to 5.0 s
1.0
09
400117
400118
Stability detection width
0: Not used
1 to 9 d
2
10
400119
400120
Tare and zero setting at
unstable weight
0: Disable
1: Enable
1
11
400121
400122
Tare at negative gross value
0: Disable
1: Enable
1
12
400123
400124
Standard serial output, when the
weight value is overloaded or
unstable.
0: Disable
1: Enable
1
13
400125
400126
BCD, RS-422/485, RS-232C
output, when the weight value is
overloaded or unstable.
0: Disable
1: Enable
1
14
400127
400128
Weighing mode
1:
2:
3:
4:
5:
6:
7:
8:
Simple comparison normal
batching
Simple comparison loss
-in
-
weight batching
Normal
batching
Loss
-in-weight batching
Check weighing
1
Check weighing
2
Check weighing
3
Check weighing 4
3
15
400129
400130
Load cell signal voltage at zero
calibration
0.000000 to 2.000000 0.000000
