21.10. RS-422/485, RS-232C Functions
rS F Modbus Item Setting Value Default
User
setting
01
400901
400902
Output weight value
1:
2:
3:
4:
5:
6:
7:
8:
Displayed weight value
Gross value
Net value
Tare value
Gross value + Net value + Tare va
lue
Total weight
Number of accumulations
Total weight and number of
accumulations
1
02
400903
400904
Communication type
1:
2:
3:
4:
5:
6:
7:
8:
9:
Interval output at the display update
rate (FncF
-03)
In synchronization with automatic print
In synchro
nization with manual print
Response to command
Interval output of comparison result
and gross value at 100 times/s
Interval output of comparison result
and net value at 100 times/s.
In
synchronization with
automatic/manual accumulation
Interval output at
100 times/s
Modbus-RTU
1
03
400905
400906
Baud rate
1: 600 bps
2: 1200 bps
3: 2400 bps
4: 4800 bps
5: 9600 bps
6: 19200 bps
7: 38400 bps
8: 115200 bps
5
04
400907
400908
Parity
0: None
1: Odd
2: Even
2
05
400909
400910
Character bit length
7: 7 bits
8: 8 bits
7
06
400911
400912
Stop bit length
1: 1 bit
2: 2 bits
1
07
400913
400914
Terminator
1:CR
2:CR LF
2
08
400915
400916
RS-422/485
electrical specifications
1: RS-422 (rS F-09=0)
1: 4-wire RS-485 (rS F-09 ≠ 0)
2: 2-wire RS-485
1
09
400917
400918
RS-422/485
slave address
0: None
1 to 99
0
10
400919
400920
Command Response
delay time
0.00 to 3.00 s
0.06
