AD-4401A
Page 53
14.8. Format When Communication Type (rS F-02) is 8
●Data format (Weight value)
Slave address Output weight value Terminator
3 chars 8 chars 2 chars/1 char
Item
Value
Output weight value
(rS F-01)
+
0 0 0 1 2 3 4
Figure with a sign
+ 0 0 0 0 0 0 0 0
+
SP SP SP SP . SP SP
Positive overload
-
SP SP SP SP . SP SP
Negative overload
A decimal point is not added to the output weight value.
