21.8. Standard Serial Output Functions
Si F Modbus Item Setting Value Default
User
setting
01
400701
400702
Output weight value
1:
2:
3:
4:
5:
6:
7:
8:
Displayed weight value
Gr
oss value
Net value
Tare value
Gross value
+ Net value + Tare value
Total weight
Number of accumulations
Total weight and number of
accumulations
1
02
400703
400704
Data output timing
1:
2:
3:
4:
Interval output at the display update
rate (FncF
-03)
In s
ynchronization with automatic print
In synchronization with manual print
In synchronization with automatic /
manual accumulation
1
03
400705
400706
Baud rate
1: 600 bps
2: 2400 bps
2
04
400707
400708
Standard serial output
slave address
0: None
1 to 99
0
21.9. BCD Output Functions
bCdF Modbus Item Setting Value Default
User
setting
01
400801
400802
Output weight value
1: Displayed weight value
2: Gross value
3: Net value
4: Tare value
1
02
400803
400804
Data output timing
1:
2:
3:
Interval output at the display update
rate (FncF
-03)
In synchronization with automatic print
In synchronization with manual print
1
03
400805
400806
Data output logic
1: Positive logic
2: Negative logic
2
04
400807
400808
Strobe output logic
1: Positive logic
2: Negative logic
2
