14.6. Format When Communication Type (rS F-02) is 1, 2, 3 or 7
●Data format (Gross value, Net value, Tare value)
Header 1
Header 2
Output weight
value
Unit
Terminator
3 chars 3 chars 8 chars 2 chars 2 chars/1 char
Item Value
Header 1
S T ,
Stable
U S , Unstable
O L , Overload
Header 2
(Si F-01)
G S ,
at CALF19=1
Gross value
N T ,
Net value
T R ,
Tare value
G SP ,
at CALF19=2
Gross value
N SP , Net value
T SP , Tare value
Output weight value
(Si F-01)
+
0 0 1 2 . 3 4
Figure with a sign
+ 0 0 0 0 0 0 0 0
+
SP SP SP SP . SP SP
Positive overload
-
SP SP SP SP . SP SP
Negative overload
Unit (CALF-01)
SP SP
None
SP g g
k g kg
SP t t
No unit is added when the number of accumulations is output.
SP: space
