21.5. Weighing Sequence Functions
Sq F Modbus Item Setting Value Default
User
setting
01
400401
400402
Comparison target
1: Internal value
2: Displayed weight value
1
02
400403
400404
Automatic accumulation
condition
0: Disable
1: OK only
2: Regardless of the judgment result
0
03
400405
400406
Automatic free fall
correction
0: Disable
1: Moving average of last four weighings
2: Fuzzy
0
04
400407
400408
Automatic free fall
correction range
0 to 9999999 0
05
400409
400410
Minimum small flow time
for the automatic free
fall correction
0.0 to 30.0 s 3.0
06
400411
400412
OK / Over / Under
output timing
1: Always
2: In synchronization with weighing end
2
07
400413
400414
Wait for the weight value
to be stable before the
judgment
0: Disable
1: Enable
1
08
400415
400416
Maximum number of
correction flow
0: Disable correction flow
1 to 300
0
09
400417
400418
Weighing start input
delay time
0.0 to 30.0 s 0.0
10
400419
400420
Large flow comparison
disable time
0.0 to 30.0 s 0.0
11
400421
400422
Medium flow
comparison disable time
0.0 to 30.0 s 0.0
12
400423
400424
Small flow comparison
disable time
0.0 to 30.0 s 0.0
13
400425
400426
Judging delay time 0.1 to 30.0 s 0.1
14
400427
400428
Weighing end output
time
0.0: Until the next weighing start
0.1 to 30.0 s
0.0
15
400429
400430
Flow timeout time
0: None
1: 1 to 86400 s
0
16
400431
400432
Correction flow ON time 0.01 to 3.00 s 0.10
17
400433
400434
Correction flow OFF
time
0.1 to 30.0 s 0.1
18
400435
400436
Discharge start input
delay time
0.0 to 30.0 s 0.0
19
400437
400438
Discharge end delay
time
0.1 to 30.0 s 0.1
20
400439
400440
Discharge timeout time
0: None
1: 1 to 86400 s
0
21
400441
400442
Add the final weight to
the near-zero setpoint
value
0: Disable
1: Enable
0
22
400443
400444
Add the final weight to
the full setpoint value
0: Disable
1: Enable
0
23
400445
400446
Reserved internally
24
400447
400448
Simple comparison
large/medium/small flow
output logic
1: Positive logic
2: Negative logic
1
