FncF Modbus Item Setting Value Default
User
setting
06
400311
400312
10
1
digit:
Pre-digital filter cutoff
frequency
10
0
digit:
Post-digital filter cutoff
frequency
Pre-digital filter and
post-digital filter are
connected in series.
0:
1:
2:
3:
4:
5:
6:
7:
8:
9:
None
11.0 Hz
8.0 Hz
5.6 Hz
4.0 Hz
2.8 Hz
2.0 Hz
1.4 Hz
1.0 Hz
0.7 Hz
48
HPDF cutoff frequency
101:
102:
103:
104:
105:
106:
107:
108:
109:
11.0 Hz (HPDF)
8.0 Hz (HPDF)
5.6 Hz (HPDF)
4.0 Hz (HPDF)
2.8 Hz (HPDF)
2.0 Hz (HPDF)
1.4 Hz (HPDF)
1.0 Hz (HPDF)
0.7 Hz (HPDF)
07
400313
400314
Sampling frequency
divider ratio
(Disabled when FncF-06
is 101 to 109)
1: (FncF-06)/1
2: (FncF-06)/2
3: (FncF-06)/3
4: (FncF-06)/4
5: (FncF-06)/5
6: (FncF-06)/6
7: (FncF-06)/7
8: (FncF-06)/8
9: (FncF-06)/9
10:((FncF-06)/10
1
08
400315
400316
Hold function
1: Normal hold
2: Peak hold
1
09
400317
400318
Comparison at hold
0: Disable
1: Enable
0
10
400319
400320
Condition to turn the
ALARM status ON
00000000:
00000001:
00000010:
00000100:
00001000:
00010000:
None
Overload
Total weight / number of
accumulations overflow
Zero setting error
Tare error
Weighing sequence error
0000
0111
