14.3. Communication Specifications
Signal level (rS F-08, rS F-09) RS-422/RS-485 compliant
Baud rate (rS F-03) 600, 1200, 2400, 4800, 9600, 19200, 38400, 115200 bps
Character bit length (rS F-05) 7, 8 bits
Parity (rS F-04) None, Odd, Even
Start bit length 1 bit
Stop bit length (rS F-06) 1, 2 bits
Code ASCII, Binary (for Modbus-RTU）
Terminator (rS F-07) CR LF, CR
14.4. Output Data
Select an output data (rS F-01) from the following:
1: Displayed weight value (default)
2: Gross value
3: Net value
4: Tare value
5: Gross value + Net value + Tare value
6: Total weight
7: Number of accumulations
8: Total weight and number of accumulations
14.5. Communication Type
Select a communication type (rS F-02) from the following:
1: Interval output at the display update rate (FncF-03) (default)
2: In synchronization with automatic print
3: In synchronization with manual print
4: Write data or read setpoint values by commands from the master
5: Interval output of comparison result and gross value at 100 times/s.
6: Interval output of comparison result and net value at 100 times/s.
7: In synchronization with automatic/manual accumulation
8: Interval output at 100 times/s
9: Modbus-RTU (available for the software version 1.03 or later)
