TABLE D -- Transmitter Configuration Settings (Ranges/Choices and Defaults) -- continued
Displayed Screen Title Entry Range or Choices (where applicable) Factory Default Your Setting
SENSOR Settings (continued)
TEMP ELEMENT:
SET T FACTOR?
950-1050 ohms 1000 ohms
TEMP ELEMENT:
SET MANUAL?
0.0-200.0°C 25.0°C
TEMPERATURE Display Setting
SET °C OR °F? °C or °F °C
OUTPUT Settings
SET PARAMETER? SENSOR or TEMPERATURE SENSOR
SET 4mA VALUE? CONDUCTIVITY:
µS/cm: 0-200.0, or 0-2000
mS/cm: 0-2.000, 0-20.00, 0-200.0 or 0-2000
S/cm: 0-2.000
CONCENTRATION: 0-99.99% or 0-200.0%
TDS: 0-9999 ppm
TEMPERATURE:
-20.0 to +200.0°C or -4.0 to 392.0°F
CONDUCTIVITY:
µS/cm: 0
mS/cm: 0
S/cm: 0
CONC: 0.00% or 0.0%
TDS: 0 ppm
TEMPERATURE:
0.0°C or 32.0°F
SET 20mA VALUE? CONDUCTIVITY:
µS/cm: 0-200.0 or 0-2000
mS/cm: 0-2.000, 0-20.00, 0-200.0 or 0-2000
S/cm: 0-2.000
CONCENTRATION: 0-99.99% or 0-200.0%
TDS: 0-9999 ppm
TEMPERATURE:
-20.0 to +200.0°C or -4.0 to 392.0°F
CONDUCTIVITY:
µS/cm: 200.0 or 2000
mS/cm: 2.000, 20.00, 200.0
or 2000
S/cm: 2.000
CONC: 99.99% or 200.0%
TDS: 9999 ppm
TEMPERATURE:
100.0°C or 212.0°F
SET FILTER? 0-60 seconds 0 seconds
SET FAIL LEVEL? OFF, 4 mA or 20 mA OFF
PASSCODE Setting
SET PASSCODE? DISABLED or ENABLED DISABLED
TEST/MAINT Simulation Function Settings
SELECT SIM? SENSOR or TEMPERATURE SENSOR
SIM SENSOR? CONDUCTIVITY:
µS/cm: 0-200.0, or 0-2000
mS/cm: 0-2.000, 0-20.00, 0-200.0 or 0-2000
S/cm: 0-2.000
CONCENTRATION: 0-99.99% or 0-200.0%
TDS: 0-9999 ppm
TEMPERATURE:
-20.0 to +200.0°C or -4.0 to 392.0°F
Present measured value of
selected parameter
