PAGE 24
Section 7 - TSection 7 - T
Section 7 - TSection 7 - T
Section 7 - T
ransmitter Configurationransmitter Configuration
ransmitter Configurationransmitter Configuration
ransmitter Configuration
NOTE: When the passcode feature is enabled (Section 7.5), you must successfully enter the
passcode before attempting to enter a configuration setting.
7.1 Selecting 7.1 Selecting
7.1 Selecting 7.1 Selecting
7.1 Selecting
LANGUAGELANGUAGE
LANGUAGELANGUAGE
LANGUAGE
to Operate T to Operate T
to Operate T to Operate T
to Operate T
ransmitterransmitter
ransmitterransmitter
ransmitter
The transmitter is normally equipped to display screens in English and Spanish (Español).
However, another language such as French (Français), German (Deutsche), etc. may be
substituted for Spanish. The transmitter is factory-set for English. To select the other language:
1. Press MENU key to display a “MAIN MENU” screen.
If the
screen is not showing, use
ØØ
ØØ
Ø or
××
××
× key to display it.
2. Press ENTER key to display
.
3. Press
ØØ
ØØ
Ø key until screen appears.
4. Press ENTER key to display
. Use
ØØ
ØØ
Ø or
××
××
× key to select a
language, and press ENTER key to enter it.
NOTE: After a language is selected and entered, all screens are displayed in that language.
7.2 Configuring Sensor Characteristics7.2 Configuring Sensor Characteristics
7.2 Configuring Sensor Characteristics7.2 Configuring Sensor Characteristics
7.2 Configuring Sensor Characteristics
The transmitter must be configured to define the characteristics of the sensor including its
temperature element type and “T” factor, and other related items such as selecting the
measurement and its format, temperature compensation, input signal filtering, etc.
SELECT MEASURE (conductivity, concentration or TDS)
1. With the screen displayed, press
ØØ
ØØ
Ø key once to display
.
2. Press ENTER key to display
.
3. Press ENTER key again to display a screen like . Use
ØØ
ØØ
Ø
and
××
××
× keys to select the desired measurement (conductivity, concentration or TDS),
and press ENTER key to enter it.
NOTE: If concentration was selected, measured conductivity must be converted to %
concentration by selecting a BUILT-IN chemical concentration table or creating a
USER-DEFINED table. See “CONFIG CONC” subheading for details.
