TABLE D -- Transmitter Configuration Settings (Ranges/Choices and Defaults)
Displayed Screen Title Entry Range or Choices (where applicable) Factory Default Your Setting
LANGUAGE Setting
LANGUAGE? ENGLISH and SPANISH (French, German,
etc. may be substituted for Spanish)
ENGLISH
SENSOR Settings
SELECT MEASURE? CONDUCTIVITY, CONCENTRATION or
TDS
CONDUCTIVITY
DISPLAY FORMAT?
(full scale value)
CONDUCTIVITY:
µS/cm: 200.0, or 2000
mS/cm: 2.000, 20.00, 200.0 or 2000
S/cm: 2.000
CONCENTRATION: 99.99% or 200.0%
TDS: 9999 ppm
CONDUCTIVITY: 200.0 mS/cm
CONCENTRATION: 99.99%
TDS: 9999 ppm
T-COMPENSATION? LINEAR, NATURAL WATER,
TEMP TABLE or NONE
LINEAR at 2.00% per °C with
25.0°C reference temperature
CONFIG CONC:
SELECT TYPE?
BUILT-IN or USER-DEFINED BUILT-IN
CONFIG CONC:
SET CHEMICAL?
NaOH 0-16%,CaCl
2
0-22%, HNO
3
0-28%,
HNO
3
36-96%, H
2
SO
4
0-30%, H
2
SO
4
40-80%,
H
2
SO
4
93-99%, H
3
PO
4
0-40%, HCl 0-18% or
HCl 23-36%
Built-in NaOH 0-16% chemical
concentration table
CONFIG CONC:
USER DEFINED?
Edit default table by entering up to 10
data points with conductivity X coordinates
and corresponding concentration Y
coordinates
Two point default conc. table:
Pt. 1: X = 0 µS/cm; Y = 0.00%
Pt. 2: X = 2000 µS/cm;
Y = 99.99%
CONFIG TDS:
SELECT FACTOR?
NaCl or USER DEFINED NaCl
CONFIG TDS:
SET FACTOR?
0.01-99.99 ppm/µS 0.49 ppm/µS
CONFIG LINEAR:
SET SLOPE?
0-4.00% per °C 2.00% per °C
CONFIG LINEAR:
SET REF TEMP?
0-200.0°C or 32-392.0°F 25.0°C or 77.0°F
CONFIG T-TABLE? Edit default table by entering up to 10
data points with temperature X coordinates
and corresponding ratio Y coordinates
(0-99.99)
Two point default temp. table:
Pt. 1: X = 0.0°C; Y = 1.00
Pt. 2: X = 100.0°C; Y = 1.00
SET FILTER? 0-60 seconds 0 seconds
ENTER NOTE? Replace COND with up to eight characters COND
TEMP ELEMENT:
SELECT TYPE?
PT1000 or MANUAL PT1000
7.6 Configuration Setting Summary7.6 Configuration Setting Summary
7.6 Configuration Setting Summary7.6 Configuration Setting Summary
7.6 Configuration Setting Summary
TABLE D lists all configuration settings and their entry ranges/choices and factory defaults,
categorized by basic functions.
