PAGE 9
Section 3 - Physical InstallationSection 3 - Physical Installation
Section 3 - Physical InstallationSection 3 - Physical Installation
Section 3 - Physical Installation
Unpack and examine the equipment even if you do not use it immediately. If there is evidence of
damage, notify the transit carrier immediately.
Recommendation: Save the shipping carton and packing materials in case the instrument must
be stored or re-shipped.
3.1 Location3.1 Location
3.1 Location3.1 Location
3.1 Location
1. It is recommended to locate the transmitter as close as possible to the installed sensor.
The maximum allowable distance between an installed sensor and the transmitter
depends upon the full-scale value you set for the transmitter measuring range:
200-2000 µS/cm
Full-scale Value
2000-2,000,000 µS/cm
Full-scale Value
200 feet (61 m) max. 300 feet (91 m) max.
NOTE: When measuring % concentration, convert the transmitter full-scale value to
conductivity to determine the maximum distance.
2. Mount the transmitter in a location that is:
• Clean and dry where there is little or no vibration.
• Protected from corrosive fluids.
• Within ambient temperature limits (-4 to +140°F or -20 to +60°C).
CAUTION:
EXPOSING THE TRANSMITTER TO DIRECT SUNLIGHT MAY INCREASE
THE OPERATING TEMPERATURE ABOVE ITS SPECIFIED LIMIT, AND
DECREASE DISPLAY VISIBILITY.
