erifying Interconnect Cable Integrityerifying Interconnect Cable Integrity
erifying Interconnect Cable Integrityerifying Interconnect Cable Integrity
erifying Interconnect Cable Integrity
1. Disconnect DC power from the transmitter. Reconnect the sensor directly to the
transmitter (purposely bypassing the interconnect cable and junction box, if used).
2. Place the sensor in a container of
saturated salt water that is at room temperature.
3. Reconnect DC power to the transmitter.
4. Verify that the transmitter conductivity reading is between 150 and 350 mS/cm. If the
reading is achieved, the interconnect cable and/or junction box connections are
probably faulty. Use a digital multimeter to check the interconnect cable for shorted or
open wires.
Section 11 - Ordering MatrixSection 11 - Ordering Matrix
Section 11 - Ordering MatrixSection 11 - Ordering Matrix
Section 11 - Ordering Matrix
MOUNTING STYLE
01 Panel Mount Kit
(includes gasket, retainer plate and four screws)
02 Wall/pipe/integral mounting
(for integral mounting, sensor Wiring Style
option 2 required)
FIXED CHARACTER
A Fixed Character
D A 2 A
