Anritsu Spectrum Master MS2712E User Manual

1-3 Recommended Test Equipment General Information
1-2 PN: 10580-00255 Rev. J MT8212E and MT8213E MM
1-3 Recommended Test Equipment
The following test equipment is recommended for use in testing and maintaining Anritsu Cell Master
Models MT8212E and MT8213E. Table 1-1 is a list of test equipment that is required for verifying the
spectrum analyzer functions. Table 1-2 is a list of test equipment that is required for verifying the spectrum
analyzer functions. Table 1-3 is a list of test equipment that is required for verifying the power meter
functions. Table 1-4 is a list of test equipment that is required for verifying the functions of installed options.
Table 1-1. Test Equipment Required for Verifying Spectrum Analyzer Functions
Instrument Critical Specification
Recommended
Manufacturer/Model
Synthesized Signal Generator Frequency: 0.1 Hz to 20 GHz,
Power Output: +16 dBm,
Step attenuator installed
Anritsu Model MG3692A/B/C
with
Options 2A, 3, 4, 22, 15x
a
(Quantity 2)
a.MG3692A models require Option 15 to achieve power of +16 dBm at 3.5 GHz. MG3692B models do not require Option 15 to
achieve power of +16 dBm at 3.5 GHz.
Power Meter Power Range: –70 dBm to +20 dBm Anritsu Model ML2438A
Power Sensor Frequency: 10 MHz to 18 GHz
Power Range: –67 dB to +20 dB
Anritsu Model MA2442D
(Quantity 2)
Frequency Reference Frequency: 10 MHz Symmetricom Model RubiSource
T&M
Low Pass Filter 50 MHz Low Pass Filter Anritsu Model 1030-96
Fixed Attenuator 10 dB Attenuation Aeroflex/Weinschel Model 44-10
Fixed Attenuator 2 dB Attenuation Aeroflex/Weinschel Model 44-2
(Quantity 2)
Fixed Attenuator 6 dB Attenuation Aeroflex/Weinschel Model 44-6
(Quantity 2)
Fixed Attenuator 20 dB Attenuation Aeroflex/Weinschel Model 44-20
(Quantity 2)
Power Splitter Frequency: DC to 18 GHz Aeroflex/Weinschel Model 1870A
Adapter Frequency: DC to 20 GHz
N(m) to N(m), 50 ohm
Anritsu Model 34NN50A
Adapter Frequency: DC to 20 GHz
K(m) to N(f), 50 ohm
Anritsu Model 34RKNF50
50 ohm Termination Frequency: DC to 18 GHz Anritsu Model 28N50-2
RF Coaxial Cable Frequency: DC to 18 GHz
N(m) to N(m), 50 ohm
Anritsu Model 15NN50-1.5C
Coaxial Cable BNC(m) to BNC(m), 50 ohm Anritsu Model 2000-1627-R
