2-34 Measure Menu Spectrum Analyzer
2-74 PN: 10580-00349 Rev. H Spectrum Analyzer MG
Use this submenu to set upper limits to the following parameters:
Main Channel Pwr: Sets the main channel power level. Use the numeric
keypad, directional arrow keys, or the rotary knob to change the power
value. When using the keypad, press the unit submenu key (dBm, for
example) to accept the power value.
ACPR Upper Adj: Sets the ACPR upper adjacent channel power value.
Use the numeric keypad, directional arrow keys, or the rotary knob to
change the value. When using the keypad, press the unit submenu key (dB)
to accept the entered value.
ACPR Lower Adj: Sets the ACPR lower adjacent channel power value.
Use the numeric keypad, directional arrow keys, or the rotary knob to
change the value. When using the keypad, press the unit submenu key (dB)
to accept the entered value.
ACPR Upper Alt: Sets the ACPR upper alternate channel power value.
Use the numeric keypad, directional arrow keys, or the rotary knob to
change the value. When using the keypad, press the unit submenu key (dB)
to accept the entered value.
ACPR Lower Alt: Sets the ACPR lower alternate channel power value. Use
the numeric keypad, directional arrow keys, or the rotary knob to change the
value. When using the keypad, press the unit submenu key (dB) to accept
the entered value.
Back: Returns to the “ACPR Menu” on page 2-73.
Figure 2-60. ACPR Limits Submenu Keys
ACPR Lower Adj
10.0 dB
ACPR Upper Alt
10.0 dB
ACPR Lower Alt
10.0 dB
ACPR Upper Adj
10.0 dB
ACPR Limits
Main Channel Pwr
10.0 dBm
Back
