Spectrum Analyzer 2-34 Measure Menu
Spectrum Analyzer MG PN: 10580-00349 Rev. H 2-83
Demod Type (AM/FM) Menu
Key Sequence: Shift > Measure (4) key > AM/FM Demod > Demod Type
Refer to Section 2-19 “AM/FM/SSB Demodulation” on page 2-25 for a description of the
built-in demodulator.
Press one of these submenu keys to select an AM/FM demodulation type.
The red circle indicates the active selection.
FM Wide Band: Frequency Modulation
FM Narrow Band: Frequency Modulation
AM: Amplitude Modulation
USB: Upper Sideband. This can also be used when demodulating CW
(Morse code) signals.
LSB: Lower Sideband. This can also be used when demodulating CW
(Morse code) signals.
Back: Returns to the “AM/FM Demod 1/2 Menu” on page 2-82.
Figure 2-69. SPA AM/FM Demod Menu
FM Wide
Band
AM
USB
LSB
FM Narrow
Band
Demod Type
Back
