2-34 Measure Menu Spectrum Analyzer
2-84 PN: 10580-00349 Rev. H Spectrum Analyzer MG
AM/FM Demod 2/2 (More) Menu
Key Sequence: Shift > Measure (4) key > AM/FM Demod > More
Squelch Power: Sets the squelch power value. Use this setting to limit
noise in the displayed signal. The squelch value is the base line limit below
which no signal is displayed.
Beat Freq Osc: Sets the beat frequency of the oscillator to exactly set the
demodulation frequency of USB and LSB signals. Displayed only when USB
or LSB is selected as the Demod Type. This can also be used when
demodulating CW (Morse code) signals.
Back: Returns to the “AM/FM Demod 1/2 Menu” on page 2-82.
Figure 2-70. SPA AM/FM Demod 2/2 Menu
AM/FM Demod 2/2
Back
Squelch Power
## dBm
Beat Freq Osc
0 Hz
