Spectrum Analyzer 2-36 Limit Menu
Spectrum Analyzer MG PN: 10580-00349 Rev. H 2-97
Edit Menu (Continued)
Add Vertical: In many measurement masks, step changes occur in the
value of the limit line. Press this submenu key to add two inflection points.
The two inflection points share the same frequency and are centered
midpoint between adjacent measured points. The magnitudes of the points
are set by using a visually intuitive algorithm that is based upon the adjacent
inflection points.
You can adjust the magnitudes independently, but the frequencies of the two
points remain linked and are adjusted as a vertical pair. Setting a discrete
frequency, a limit inflection point will keep that exact frequency and place the
limit point appropriately regardless of the frequency span. This is especially
useful for emission mask verification.
Delete Point: Press this submenu key to delete the currently active point.
The active point becomes the point that is immediately to the left of the point
that was deleted.
Next Point Left: Press this submenu key to select the inflection point that is
immediately to the left of the active point, making this newly selected point
active for editing or deletion. With each key press, the active point becomes
that point to the left of the previously active point, until the newly selected
active point becomes the left-most point on the screen.
Next Point Right: Press this submenu key to select the limit point
immediately to the right of the active point, making this newly selected point
active for editing or deletion. With each key press, the active point becomes
that point to the right of the previously active point, until the newly selected
active point becomes the right-most point on the screen.
Back: Press this submenu key to return to the “Limit Menu” on page 2-95.
Figure 2-83. SPA Limit Edit Menu (2 of 2)
Edit
Back
Frequency
1.964 718 182 GHz
Amplitude
-75.0 dBm
Add
Point
Add
Vertical
Delete
Point
Next
Point
Left
Next
Point
Right
